Figure 2. Mean hodographs for the winds within 30 km of center
of Hurricane Olivia on 25 September during the first and last penetrations
of the storm core. The upper panel shows the very weak westerly shear
during the first penetration, while the lower panel shows a westerly shear
of more than 15 m/s.
