Differences of temperature and salinity for each profile
(Click on the figure for a larger version with links to individual profiles).
| Comparison dataset | Temperature | ||||
|---|---|---|---|---|---|
| nobs | mean | std dev | slope | intercept | |
| Levitus (WOA05) | 80 | 0.2334 | 0.2604 | -0.0005 | 0.4216 |
| Navy (GDEM3)) | 80 | 0.3574 | 0.2628 | -0.0004 | 0.5105 |
| Argo-only | 80 | 0.0546 | 0.2147 | -0.0003 | 0.1693 |
| Buddies | 7 | -0.0707 | 0.2785 | 0.0002 | -0.1361 |
| Comparison dataset | Salinity | ||||
|---|---|---|---|---|---|
| nobs | mean | std dev | slope | intercept | |
| Levitus (WOA05) | 80 | 0.0129 | 0.0162 | -0.00003 | 0.0238 |
| Navy (GDEM3)) | 80 | 0.0107 | 0.0183 | -0.00003 | 0.0240 |
| Argo-only | 80 | 0.0051 | 0.0172 | -0.00001 | 0.0105 |
| Buddies | 6 | 0.0088 | 0.0118 | 0.00002 | 0.0031 |
Differences of temperature and salinity for each profile
(Click on the figure for a larger version with links to individual profiles).
| General information | Number of Profiles | Dates | |||
|---|---|---|---|---|---|
| Float WMOId | 1900286 | Total | 132 | Creation | 20120307030931 |
| Principal Investigator | Jon Turton | Real time | 0 | Update | 20120307030931 |
| Data Center | BO | Adjustedtime | 0 | Analysis | 20130722124401 |
| Instrument reference | APEX-SBE 1193 | Delayed_mode | 132 | ||
Click HERE for a table with information on each profile, including links to the individual profile pages.
| Notes | |
| 1 | ANOM WARN There are cases where PRES_ADJUSTED_QC=4, but temp and/or psal adjusted qc are not |
Last update: 29-Jul-2013
