Effects of Synoptic Surveillance on model forecasts for
13 August 1999 1200 UTC
EUGENE.


QuickTime movie of DLM wind model forecasts
QuickTime movie of DLM wind data increments


TRACK AND INTENSITY PERFORMANCE

TRACK (km)
MODEL12 h24 h36 h48 h60 h72 h84 h96 h108 h120 h
AVNN116.151.249.380.
AVAL124.238.342.416.
%IMP-7%-58%-37%-9%
GFNO43.102.185.263.
GFAL21.92.219.227.
%IMP51%10%-18%14%
INTENSITY (kt)
MODEL12 h24 h36 h48 h60 h72 h84 h96 h108 h120 h
AVNN-17.-8.-4.-4.
AVAL-19.-10.-5.-6.
%IMP-12%-25%-25%-50%
GFNO2.16.23.23.
GFAL3.8.25.22.
%IMP-50%50%-9%4%
SHNO11.22.28.26.
SHAL11.22.27.24.
%IMP0%0%4%8%
DSNO11.22.28.26.
DSAL11.22.27.24.
%IMP0%0%4%8%

Figure 1. NCEP 850 - 200 hPa mean wind analysis for 13 August 1999 1200 UTC (Tropical Storm Eugene).

Figure 2. Track forecasts for the no dropwindsonde (NO or NN) and the all dropwindsonde (AL) runs for the AVN and GFDL models initialized on 13 August 1999 1200 UTC. The best track is shown in black.

Figure 3. Initial condition differences in the 850 - 200 hPa mean wind between the no and all dropwindsonde cases for 13 August 1999 1200 UTC.

Figure 4. 13-h forecast differences in the 850 - 200 hPa mean wind between the no and all dropwindsonde cases for 13 August 1999 1200 UTC.
